API 653 ABOVE GROUND TANK INSPECTOR PREPARATORY COURSE IN ALEXANDRIA

API 653 ABOVE GROUND TANK INSPECTOR PREP COURSE

Date	14 to 18 April  2013
Duration	5 Days
Time	4:00 pm to 9:00 pm
Fees	2000 EGP
Location	Alexandria
Reservation	002/ 01002140609

Course Content:

The main emphasis of this programme is on safe storage and material handling of petroleum products in a manner that protects employees, the public, and the environment. It provides the oil, gas and petrochemical industry with the assurance that storage tank inspectors trained and certified under this internationally recognised programme have the required knowledge and experience for the job in the field.

Course participants aspiring to be certified by American Petroleum Institute will undergo a rigorous programme to get them well versed with the various code books and standards, including API Standards that cover inspection, repair, alteration and reconstruction of the above ground storage tank

For details Contact:
EGYPT –Main Office
29, Ahmed Allam st, Al Ibrahymia,  Alexandria, Egypt.
Egypt Mob. : 002 01002140609
Telefax : 002 03 591 8968

AEC-Abu Dhabi -UAE
38, 3^rd Floor , Cornish Building , Khaldyia, Abu Dhabi,UAE
P.O. Box : 39365
Phone: 00971 2 6280 150
Fax :     00971 2 6280 360
UAE Mob. :  00971 508112505
E-mail : ghada@sa-egypt.org


ASME SECTION VIII DIVISION 1 DESIGN AND FABRICATION FOR PRESSURE VESSEL COURSES IN CAIRO, EGYPT

ASME SECTION VIII DIVISION 1 DESIGN AND FABRICATION FOR PRESSURE VESSEL  COURSES IN CAIRO, EGYPT

Date	21 – 25 APRIL, 2013
Duration	5 Days
Time	4:00 pm to 9:00 pm
Fees	2000 EGP
Location	Alexandria Or Cairo
Reservation	002/ 01002140609

ASME Section VIII Division 1 Design and Fabrication for Pressure Vessels Based on the rules for pressure vessel design and construction, this course is a comprehensive introduction to the requirements of Section VIII, Division 1 including background, organization, design, materials, fabrication, inspection, testing and documentation of pressure vessels. The more commonly used subsections and paragraphs will be covered, and a discussion of individual problems or situations will be included. This course is intended for beginners, as well as experienced vessel designers who would like to update their knowledge of the Code.

Upon Completion of This Course you will know:

• The background of the Code rules
• How to apply the Code rules to more common design and fabrication situations
• How to perform calculations for some of the loadings and situations not addresses by the Code
• How to prepare design specifications, design reports, Data Reports, and other documentation
• The certificate is issued from SA - International.

Who Should Attend?
Those involved with the purchase, design, fabrication, or inspection of pressure vessels. Some technical background will be helpful, but attendees are not required to have an Engineering degree or previous work experience in the subject matter.

Special Features:
An overview of code organization, editions and addenda will be given, and participants will learn how to prepare and submit an inquiry to the Code Committee for Code Interpretation, Code Cases or Code revision

For details Contact:
EGYPT –Main Office
29, Ahmed Allam st, Al Ibrahymia,  Alexandria, Egypt.
Egypt Mob. : 002 01002140609
Telefax : 002 03 591 8968

AEC-Abu Dhabi -UAE
38, 3^rd Floor , Cornish Building , Khaldyia, Abu Dhabi,UAE
P.O. Box : 39365
Phone: 00971 2 6280 150
Fax :     00971 2 6280 360
UAE Mob. :  00971 508112505
E-mail : ghada@sa-egypt.org

Our deepest Condolences to the Good Friend of NDT Community

Good Morning to Everyone..from Trinity NDTians

Visit us: www.trinityndt.com

Like us : www.facebook.com/trinityndt.in

Nondestructive testing (NDT) Procedures- Magnetic particle Inspection procedure free download

Download the 'Trinity NDT' free Magnetic particle inspection procedure at the following link:

Nondestructive testing (NDT) Procedures- Magnetic particle testing free download

For more downloads visit: www.trinityndt.com

Like us: www.facebook.com/trinityndt.in

Call us on : +91 98441 29439 / 99009 29439 / 72040 29439 to know more about world class facilities

Nondestructive testing (NDT) Procedures- Liquid/Dye Penetrant Inspection procedure free download

There a numerous request from the clients and NDT training participants for detailed sample NDT procedures which can help them to modify these as per specific requirements.

Responding to the requests to help the NDT community, 'Trinity NDT' is bringing you a series of free NDT procedures for download.

Download the free procedure at the following link:

Nondestructive testing (NDT) Procedures- Liquid/Dye Penetrant testing free download

For more downloads visit: www.trinityndt.com

Like us: www.facebook.com/trinityndt.in

Call us on : +91 98441 29439 / 99009 29439 / 72040 29439 to know more about world class facilities

Holi- A Wonderful and colourful festival of India wishes to you all!

Best wishes for the festival of Colours. Celebrate and enjoy the moments with your near and dear ones. Have a Great day of Holi festival...

by Trinity NDTians

Visit: www.trinityndt.com

Like: www.facebook.com/trinityndt.in

Trinity NDT is now a Life Member of Association of NDT Services Organisations of India (NANSO), Mumbai

'Trinity NDT' is now a Life Member of Association of  NDT Services Organisations of India (NANSO), Mumbai, India

Visit: www.trinityndt.com

Like us on Facebook: www.facebook.com/trinityndt.in

List of standard ASTM Reference Radiographs published by ASTM International

List of standard ASTM Reference Radiographs for Industrial Radiography

Designation	Title
E155 - 10	Standard Reference Radiographs for Inspection of Aluminum and Magnesium Castings
E186 - 10	Standard Reference Radiographs for Heavy-Walled (2 to 4½-in. (50.8 to 114-mm)) Steel Castings
E192 - 04(2010)e1	Standard Reference Radiographs of Investment Steel Castings of Aerospace Applications
E242 - 01(2010)	Standard Reference Radiographs for Appearances of Radiographic Images as Certain Parameters Are Changed
E272 - 10	Standard Reference Radiographs for High-Strength Copper-Base and Nickel-Copper Alloy Castings
E280 - 10	Standard Reference Radiographs for Heavy-Walled (4½ to 12-in. (114 to 305-mm)) Steel Castings
E310 - 10	Standard Reference Radiographs for Tin Bronze Castings
E390 - 11	Standard Reference Radiographs for Steel Fusion Welds
E431 - 96(2011)	Standard Guide to Interpretation of Radiographs of Semiconductors and Related Devices
E446 - 10	Standard Reference Radiographs for Steel Castings Up to 2 in. (50.8 mm) in Thickness
E505 - 01(2011)	Standard Reference Radiographs for Inspection of Aluminum and Magnesium Die Castings
E592 - 99(2009)e1	Standard Guide to Obtainable ASTM Equivalent Penetrameter Sensitivity for Radiography of Steel Plates 1/4 to 2 in. (6 to 51 mm) Thick with X Rays and 1 to 6 in. (25 to 152 mm) Thick with Cobalt-60
E689 - 10	Standard Reference Radiographs for Ductile Iron Castings
E802 - 95(2010)	Standard Reference Radiographs for Gray Iron Castings Up to 4 1/2 in. (114 mm) in Thickness
E1320 - 10	Standard Reference Radiographs for Titanium Castings
E1648 - 95(2011)	Standard Reference Radiographs for Examination of Aluminum Fusion Welds
E1936 - 03(2011)	Standard Reference Radiograph for Evaluating the Performance of Radiographic Digitization Systems
E1955 - 04(2009)	Standard Radiographic Examination for Soundness of Welds in Steel by Comparison to Graded ASTM E 390 Reference Radiographs
E2422 - 11	Standard Digital Reference Images for Inspection of Aluminum Castings
E2660 - 11	Standard Digital Reference Images for Investment Steel Castings for Aerospace Applications
E2669 - 11	Standard Digital Reference Images for Titanium Castings

To purchase the above visit ASTM International Website: www.astm.org

Conserve Water-A Trinity NDT Initiative on World Water Day 22nd March 2013

         Conserve Water-A Trinity NDT Initiative on World Water Day 22nd March 2013

Visit: www.facebook.com/trinityndt.in

Comparision between LED based UV light & Conventional UV lights for NDT Inspections

Certainly there is an increasing demand for LED Based Ultraviolet Lights (UV) when compared to conventional UV Lights used in Nondestructive tests. It is worth to understand the advantage one over the other before ordering from the NDT Equipment Suppliers.
Comparison between LED based UV light & Conventional UV lights for NDT Inspections in Liquid Penetrant & Magnetic Particle Inspections.

Parameters	LED Based UV Light	Conventional UV Light	Advantages
Average rated life	15000-20000 Hrs	2000-2500 Hrs	At least 10 times better life
Power consumption	7.5 Watt/Hr	125Watt/Hr.	Energy saving
Operating voltage	12-18V AC/DC	230V AC	Energy saving
UV output at 15" from lens	5300 µW/cm²	5200 µW/cm²	Better intensity
Intensity reduction	Drops on 8-10% over the entire life of LED	Reduces substantially as per uses & at every Switch ON-OFF	Much better life
Time Needed to reach full intensity	Within a second	Wait for 15-20 minutes	Minimises production loss
Weight	0.7 Kg	2.5 Kg	Easy to handle
Heat Generation	Negligible	High heat generated	Operator Friendly (Specially in Hot summer days)
Risk Due to UV Radiation	No risk since it emits only UV-A radiation	Also emits UV-B radiation (That is why filter needed)	Safe for Human Being
Environment Friendly	Does not contain Mercury	Contains Mercury	Safe for environvement
Focussed Rays	More sensitive to minute cracks & no irriatation on eyes	Does not have this advantage	Increased sensitivity & operator friendly
Comfort Level for operator	Increased comfort due to negligible heat ,more focused rays & lesser weight	Does not have this advantage	More operator friendly
Flickering (Due to high Voltage variation in Forging units/Press Shop)	No Flickring	Light goes off momentary	Better life & inspection does not hamper
When bought near Coil Field	Does not get switched off	Light goes off momentary	Increased productivity
Long Life & Cost Saving	Long life of LED,No Filters & Bulb used	Frequent replacement of UV Bulb & Filters	Cost Saving
Increased Life of UV Light	Life can be increased further & power can be saved only when it is required to switch on the light	It is recommended to Swich ON continuosly for the entire shift, if the inspection to done since each time switching ON -OFF the light reduces its life by 2-3 Hrs.	Increased life & energy saving
Battery Operated	Can also run on battery with very small investment	High investment needed for battery operated	Cost Saving
Effect of Water & Oil	Having no effect if the water falls on light	Very likely changes of breakage of Filters & bulb (Since these are hot while in operation)	Cost Saving
Spares availability	Easily available	Not easily available since these need to be imported	Cost Saving
